Male Rod End No.
|
Dimensions in Inches
|
α°
≈
|
Radial Static Load(lbs)
|
|
|
D
+0.0015
-0.0005
|
B
+0.00
-0.005
|
C1
Ref.
|
h
+.005
-.005
|
d2
+.010
-.010
|
Ball
Dia.
Ref.
|
l1
+.062
-.061
|
d3
Thread
UNF-3A
|
|
|
Right
Hand
|
Left
Hand
|
KM
|
KM--/H
|
|
|
KMR3
|
KML3
|
.1900
|
.312
|
.250
|
1.250
|
.625
|
.437
|
.750
|
10-32
|
13
|
1,820
|
2,850
|
|
|
KMR4
|
KML4
|
.2500
|
.375
|
.281
|
1.562
|
.750
|
.500
|
1.000
|
1/4-28
|
16
|
3,360
|
5,260
|
|
|
KMR5
|
KML5
|
.3125
|
.437
|
.344
|
1.875
|
.875
|
.625
|
1.250
|
5/16-24
|
14
|
4,320
|
7,640
|
|
|
KMR6
|
KML6
|
.3750
|
.500
|
.406
|
1.938
|
1.000
|
.719
|
1.250
|
3/8-24
|
12
|
6,090
|
9,540
|
|
|
KMR7
|
KML7
|
.4375
|
.562
|
.437
|
2.125
|
1.125
|
.812
|
1.375
|
7/16-20
|
14
|
6,560
|
10,280
|
|
|
KMR8
|
KML8
|
.5000
|
.625
|
.500
|
2.438
|
1.312
|
.937
|
1.500
|
1/2-20
|
12
|
10,350
|
16,230
|
|
|
KMR10
|
KML10
|
.6250
|
.750
|
.562
|
2.625
|
1.500
|
1.125
|
1.625
|
5/8-18
|
16
|
11,440
|
17,950
|
|
|
KMR12
|
KML12
|
.7500
|
.875
|
.687
|
2.875
|
1.750
|
1.312
|
1.750
|
3/4-16
|
14
|
17,310
|
28,080
|
|
|
Female Rod End No.
|
Dimensions in Inches
|
α°
≈
|
Radial Static Load(lbs)
|
|
|
D
+0.0015
-0.0005
|
B
+0.00
-0.005
|
C1
Ref.
|
h
+.005
-.005
|
d2
+.010
-.010
|
Ball
Dia.
Ref.
|
l1
+.062
-.061
|
d3
Thread
UNF-3A
|
|
|
Right
Hand
|
Left
Hand
|
KF
|
KF--/H
|
|
|
KFR3
|
KFL3
|
.1900
|
.312
|
.250
|
1.250
|
.625
|
.437
|
.750
|
10-32
|
13
|
1,820
|
2,850
|
|
|
KFR4
|
KFL4
|
.2500
|
.375
|
.281
|
1.562
|
.750
|
.500
|
1.000
|
1/4-28
|
16
|
3,360
|
5,260
|
|
|
KFR5
|
KFL5
|
.3125
|
.437
|
.344
|
1.875
|
.875
|
.625
|
1.250
|
5/16-24
|
14
|
4,320
|
7,640
|
|
|
KFR6
|
KFL6
|
.3750
|
.500
|
.406
|
1.938
|
1.000
|
.719
|
1.250
|
3/8-24
|
12
|
6,090
|
9,540
|
|
|
KFR7
|
KFL7
|
.4375
|
.562
|
.437
|
2.125
|
1.125
|
.812
|
1.375
|
7/16-20
|
14
|
6,560
|
10,280
|
|
|
KFR8
|
KFL8
|
.5000
|
.625
|
.500
|
2.438
|
1.312
|
.937
|
1.500
|
1/2-20
|
12
|
10,350
|
16,230
|
|
|
KFR10
|
KFL10
|
.6250
|
.750
|
.562
|
2.625
|
1.500
|
1.125
|
1.625
|
5/8-18
|
16
|
11,440
|
17,950
|
|
|
KFR12
|
KFL12
|
.7500
|
.875
|
.687
|
2.875
|
1.750
|
1.312
|
1.750
|
3/4-16
|
14
|
17,310
|
28,080
|
|
|
Specifications
|
Body
|
Race
|
Ball
|
|
Carbon Steel Duty
”K” Series
|
Carbon steel, heat treated protective coated
|
Carbon steel, heat treated, protective coated
|
SAE52100 steel,heat treated & hard
chrome plated
|
|
Alloy Steel Duty
”K--/H” Series
|
Alloy steel, heat treated protective coated
|
|
